Name: Easy Cleanig Glass Reactor Vessel , Chemical Glass Reactor Equipment Container
Brand: Nantong Sanjing Chemglass Co.,Ltd
SKU: FPGR-20
Availability: InStock

Home Products Glass Reactor Vessel

Easy Cleanig Glass Reactor Vessel , Chemical Glass Reactor Equipment Container

Product Details:

Place of Origin:	CHINA
Brand Name:	NTSJ
Certification:	CE,ISO9001
Model Number:	FPGR-20

Payment & Shipping Terms:

Minimum Order Quantity:	1 set
Price:	Negotiable
Packaging Details:	The glass parts will be wrapped with foam, then put into the carton; the mainbody portion will be packde in wooden case.
Delivery Time:	within 5days after payemnt received
Payment Terms:	L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability:	500 sets/momth

Contact Now

Detailed Product Description

Condition:	New	Certification:	CE ISO
Moving Mode:	Brake Type Universal Corner Wheel	Vacuum Degree:	-0.098mpa
Glass Material:	High Borosilicate Glass	Frame Material:	Stainless Steel
Highlight:	lab glass reactor , borosilicate glass reactor

Double layers Jacketed Glass Reactor is designed for controlling temperature of its reaction contents, by using a cooling or heating "jacket" around the vessel where the cooling or heating fluid is circulated among, under normal or negative pressure. Hawach offer a wide range of glass reactors with volumes from 1 L to 200L. It is offen connected with circulating water vacuum pump, diaphragm vacuum pump, recirculating chiller and heater equipment. It can be used in the experiment and production of chemistry, fine chemical engineering, biological pharmacy and synthesis of new materials.

Excellent Materials

1. The complete glass is made of high borosilicate glass GG17 3.3, which has good chemical and physical properties.

2. The mixing paddle is made of stainless steel wrapped PTFE for the low and high viscosity liquids.

3. As the material of mechanical frame is alloy steel and PTFE joint, it can get high precision seals under working conditions.

Convenient Design

1. Equipped with frequency control and geared motor, it can work continuously at a constant speed, without brush and spark issues.

2. The lower discharge port has a flange port and a PTFE valve. The detachable design ensure the solid materials discharge more easily, and make the discharge more thorough and fast.

The glass reactor systems are the essential equipment for mixing, reaction, distillation and filtration in chemistry and pharmaceutical industries.
A jacketed vessel is a container that is designed for controlling temperature of its contents.
By using a cooling or heating "jacket" around the vessel through which a cooling or heating fluid is circulated.

The full transparent reaction process is an ideal test equipment for modern fine chemicals, new biochemicals research and development, pharmaceutical intermediates, precious metals purification, new graphene energy materials and aerospace materials. We keeps pace with the times, can provide the reaction kettle system from simple kettle to complex process. The product can be used with circulating water multipurpose vacuum pump, high and low temperature circulation device, one-stop matching, for your free expansion of the ideal choice of reaction synthesis.

Product Model	PGR-3	PGR-5	PGR-10	PGR-30	PGR-50	PGR-100	PGR-200
Volume(L)	3	5	10	30	50	100	200
Neck No.on Cover	4	5	6	6	6	6	6
External Diameter of Inner Vessel(mm)	150	180	230	330	365	460	600
External Diameter of Outer Vessel(mm)	200	230	290	365	410	500	650
Cover Diameter(mm)	150	180	265	265	265	340	340
Vessel Height(mm)	300	400	450	730	850	950	1200
Motor Power(W)	40	60	140	140	140	250	750
Vacuum Degree(Mpa)	0.098	0.098	0.098	0.098	0.098	0.098	0.098
Rotation Speed(rpm)	50-1400	50-600	50-600	50-600	50-600	50-600	50-600
Torque(Nm)	0.27	0.95	2.23	2.23	2.23	3.98	6.37
Power(V)	220	220	220	220	220	220	220
Dimension(mm)	320350900	4504501200	6506501900	7005002100	8006002300	10007002700	12009003200

Main features

Customizable

The blades are available in PTFE,stainless steel and can be clamped on the stirring shaft.

An additional vacuum jacket on the vessel can provide thermal insulation, get rid of frost and keep clear vision inside the vessel
We offer thermo- fluid ports in different forms (glass barb,stainless steel barb, flange, NPT thread, etc).
